2-WP-5040-5 - YVO4 Wollaston Polarizer, 20 mm clear aperture, 500 - 4000 nm

2-WP-5040-5

Plus de vues

2-WP-5040-5 - YVO4 Wollaston Polarizer, 20 mm clear aperture, 500 - 4000 nm
2 265,00 $US
The device consists of two calcite prisms cemented in such way that they deviate the two emerging beams by nearly equal amount in opposite directions.

Angular Field, deg 20.0 @1550 nm
Ouverture utile, mm 20
Extinction Ratio <5 x 10-5
Length, mm 29
Material YVO4
Outside Diameter, mm 38
Longueur d'onde, nm 500 - 4000
Delivery 2-4 weeks
Description

Détails

The device consists of two calcite prisms cemented in such way that they deviate the two emerging beams by nearly equal amount in opposite directions.
Fonctionnalités
  • Wide Wavelength Range
  • Low Power Application
  • High extinction ratio
