2-WP-3530-4 - Calcite Wollaston Polarizer, 15 mm clear aperture, 350 - 3000 nm

2-WP-3530-4

Plus de vues

2-WP-3530-4 - Calcite Wollaston Polarizer, 15 mm clear aperture, 350 - 3000 nm
1 190,00 $US
The device consists of two calcite prisms cemented in such way that they deviate the two emerging beams by nearly equal amount in opposite directions.

Angular Field, deg 2.0 @980 nm
Ouverture utile, mm 15
Extinction Ratio <5 x 10-5
Length, mm 28
Material Calcite
Outside Diameter, mm 30
Longueur d'onde, nm 350 - 3000
Delivery 2-4 weeks
Description

Détails

The device consists of two calcite prisms cemented in such way that they deviate the two emerging beams by nearly equal amount in opposite directions.
Fonctionnalités
  • Wide Wavelength Range
  • Low Power Application
  • High extinction ratio
