2-WP-2023-5 - Quartz Wollaston Polarizer, 20 mm clear aperture, 200 - 2300 nm

2-WP-2023-5

Plus de vues

2-WP-2023-5 - Quartz Wollaston Polarizer, 20 mm clear aperture, 200 - 2300 nm
1 540,00 $US
The device consists of two calcite prisms cemented in such way that they deviate the two emerging beams by nearly equal amount in opposite directions.

Angular Field, deg 16.0 @1064 nm
Ouverture utile, mm 20
Extinction Ratio <5 x 10-4
Length, mm 48
Material Quartz
Outside Diameter, mm 38
Longueur d'onde, nm 200 - 2300
Delivery 2-4 weeks
Description

Détails

The device consists of two calcite prisms cemented in such way that they deviate the two emerging beams by nearly equal amount in opposite directions.
Fonctionnalités
  • Wide Wavelength Range
  • Low Power Application
  • High extinction ratio
