1-OS-2-4020-5-[1R45-GDD] 45deg, 1020-1090 nm, UVFS, Low GDD Ultrafast Mirror, 40 x 20 x 5 mm, R>99.4%

Plus de vues

1-OS-2-4020-5-[1R45-GDD] 45deg, 1020-1090 nm, UVFS, Low GDD Ultrafast Mirror, 40 x 20 x 5 mm, R>99.4%
171,60 $US
Low GDD Ultrafast mirrors are designed for femtosecond applications to provide an optimized performance at certain wavelength and angle of incidence (AOI). This is achieved by careful selection of coating stacks to combine high reflectivity and low GDD value (from -10 fs2 to 10 fs2 at design bandwidth) at the same time. Such coatings are used for external beam manipulation applications where pulse broadening effect is undesirable. Low GDD Ultrafast mirrors are intended for Ti:Sapphire, Nd:Glass, Er:Glass or Ytterbium doped host based lasers working in femtosecond regime. Variety of catalogue components allows to choose the right mirror for fundamental wavelength as well as for harmonics.
AOI, deg 45
Reflectivity ( average), % >99.4
Size, mm 40 x 20 x 5
Longueur d'onde, nm 1020-1090
Delivery 2-4 weeks
Description

Détails

Low GDD Ultrafast mirrors are designed for femtosecond applications to provide an optimized performance at certain wavelength and angle of incidence (AOI). This is achieved by careful selection of coating stacks to combine high reflectivity and low GDD value (from -10 fs2 to 10 fs2 at design bandwidth) at the same time. Such coatings are used for external beam manipulation applications where pulse broadening effect is undesirable. Low GDD Ultrafast mirrors are intended for Ti:Sapphire, Nd:Glass, Er:Glass or Ytterbium doped host based lasers working in femtosecond regime. Variety of catalogue components allows to choose the right mirror for fundamental wavelength as well as for harmonics.
Fonctionnalités
  • Other dimensions and wavelengths are available in small and mass production quantities
  • GDD values ranges from -10 fs2 to 10 fs2 at design bandwidth
