LPA-OEM-1064 - OEM Motorized Laser Power Attenuator, 1064 nm

More Views

LPA-OEM-1064 - OEM Motorized Laser Power Attenuator, 1064 nm

OEM Laser power attenuator (LPA-OEM) is a compact, cost-effective motorized laser power control unit designed for integration.

Design Wavelength, nm 1064
Attenuation range 0.1 - 98 %
LIDT 10 J/cm2 (10 ns @ 1064 nm)
Contrast 1:1000
Description

Details

The LPA-OEM is produced in the UV, visible and NIR spectral ranges, from 250 nm to 2000 nm. This device is combined with a unique mechanical design which ensures repeatability and high stability of performance. Optical components of the LPA are made for high LIDT and provide stable and reliable performance even using them with high-power lasers in industrial applications.

Features
  • Compact, cost-effective design
  • Detachable controller for better integration
  • 175,543 μsteps in full rotation
  • ±10 μsteps accuracy (± 0.02 deg, less than ± 0.05 % of laser power)
  • Fast adjustment - less than 0.2 sec (min to max)
  • High damage threshold up to 10 J/cm2 (10 ns @ 1064 nm)
  • Adjustable polarizer angle for the highest contrast
Applications
  • Precise laser micromachining
  • Laser power stabilization
  • Research
  • Laser integration
